Vertical Tensile Tester

Name: Vertical Tensile Tester
Brand: ADVANCE TECH INSTRUMENTS
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Vertical Tensile Tester Specification

Specimen Size
Max 30 mm width, up to 1000 mm length Millimeter (mm)

Equipment Type
Vertical Tensile Tester

Resolution
0.01 N

Product Type
Tensile Tester

Automation Grade
Semi-automatic

Operating Voltage
220 V Volt (V)

Application
Tensile, elongation and break strength testing of fabrics, films, rubbers, etc.

Humidity
20%~80% RH

Number of Specimens
1 per test (single grip system)

Test Range
0~5000 N

Color
Black

Temperature
10C~40C Celsius (oC)

Interface Type
USB / RS232

Display Type
Digital LCD

Power
750 Watt (w)

Features
Microprocessor control, Safety shield, Emergency stop

Frequency
50 Hz Hertz (HZ)

Max Height
1500 mm

Power Supply
220 V / 50 Hz

Voltage
220 Volt (v)

Accuracy
0.5% of reading %

Mounting Type
Floor standing

Gas Pressure
0.5~0.7 MPa mpa

Measuring Range
0~5000 N Newton

Response Time
2 s Seconds

Usage
Laboratory / Industrial

Capacity
5000 N Ton

Machine Weight
80 kg Kilograms (kg)

Test Speed
50~500 mm/min (adjustable)

Test Width
30-300 mm Millimeter (mm)

Test Stroke
1000 mm

Control Mode
AUTO / MANUAL

Vertical Tensile Tester Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Units Per Month

Delivery Time
7-10 Days

Main Domestic Market
All India

About Vertical Tensile Tester

Experience the opulent performance of our Vertical Tensile Testercrafted with powder coated steel for unrivaled durability. This valuable tool features a high-precision, interchangeable load cell and an invincible safety system including overload protection and travel limit switches. Explore effortless result evaluation with included software, USB and RS232 data outputs. Versatility is assured thanks to interchangeable pneumatic/manual grips and a touch key interface with pre-set test programs. Try now to secure this scarce opportunity for exceptional tensile, elongation, and break strength testing compliance to ASTM and ISO standards. Ideal for laboratories and industrial use.

User Guidance: How to Operate the Vertical Tensile Tester

To use the Vertical Tensile Tester, mount the specimen securely between the appropriate grips, select your test program via the digital touch panel, and ensure the sample aligns with the test width and length specifications. Adjust test speed and stroke as required for your material. The machines digital display guides you at every step. This tester is ideal for application on fabrics, films, and rubbers to measure tensile, elongation, and break strength with accuracy and efficiency.

Sample Policy and Packaging Information

Our sample valuation process ensures that each Vertical Tensile Tester meets rigorous standards before being shipped. Limited samples are available on request, providing confidence in your investment. Shipped goods are packaged securely with all required accessories, user manual, and grips. Each unit is verified for damage-free delivery, so you receive a comprehensive and ready-to-use tensile testing solution with every shipped order.

FAQs of Vertical Tensile Tester:

Q: How does the Vertical Tensile Tester improve laboratory and industrial testing?

A: The Vertical Tensile Tester streamlines tensile, elongation, and break strength analysis with high precision, intuitive controls, and standardized compliance, enhancing reliability and efficiency in laboratory and industrial environments.

Q: What materials can be tested using this equipment?

A: This tester is designed for various materials, including fabrics, films, rubbers, and similar substrates, making it versatile across multiple applications.

Q: Where can the data from the tests be exported or stored?

A: Test results can be easily exported and stored via the built-in USB and RS232 ports, and further analyzed using the included evaluation software.

Q: When is the overload protection system activated?

A: The overload protection system engages if the applied force exceeds safe thresholds, ensuring the machine and samples remain protected during use.

Q: What benefits does the interchangeable grip system provide?

A: The interchangeable pneumatic and manual grips allow users to adapt quickly to different sample types and sizes, enabling wider usage and improved convenience.

Q: How is operator safety ensured during testing?

A: Safety features include overload protection, a travel limit switch, a safety shield, and an emergency stop function, all designed to protect users while operating the machine.
